LG G5

Versions: H850 (Europe); LG G5 Speed H858 (Taiwan); VS987 (Verizon); H820 (AT&T); LS992 (Sprint); H830 (T-Mobile); US992 (US Cellular); Vodafone
Also known as LG G5 Dual H860N with dual-SIM card slots

Network
Technology	GSM / CDMA / HSPA / LTE
2G bands	GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only)
	CDMA 800 / 1900 - VS987, US992
3G bands	HSDPA 850 / 900 / 1900 / 2100 - H850
	HSDPA 850 / 1700(AWS) / 1900 / 2100 - H830, US992
	HSDPA 850 / 1900 / 2100 - H820 CDMA2000 1xEV-DO - VS987
	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - H860N
4G bands	LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 17(700), 20(800), 28(700), 38(2600), 40(2300) - H850
	LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 12(700), 20(800) - H830
	LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 12(700), 20(800), 29(700), 30(2300) - H820
	LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 17(700), 20(800), 28(700), 38(2600), 39(1900), 40(2300), 41(2500) - H860N LTE 2,3,4,5,7,13 - VS987 LTE 2,4,5,12,13,17,25 - US992
Speed	HSPA 42.2/5.76 Mbps, LTE-A Cat6 300/50 Mbps or LTE-A Cat9 (3CA) 450/50 Mbps, EV-DO Rev.A 3.1 Mbps
GPRS	Yes
EDGE	Yes

Launch
Announced	2016, February
Status	Available. Released 2016, April

Body
Dimensions	149.4 x 73.9 x 7.7 mm (5.88 x 2.91 x 0.30 in)
Weight	159 g (5.61 oz)
Build	Aluminum body
SIM	Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by)

Display
Type	IPS LCD capacitive touchscreen, 16M colors
Size	5.3 inches, 77.4 cm2 (~70.1% screen-to-body ratio)
Resolution	1440 x 2560 pixels, 16:9 ratio (~554 ppi density)
Protection	Corning Gorilla Glass 4
	Always-on display

Platform
OS	Android 6.0.1 (Marshmallow), upgradable to Android 8.0 (Oreo); LG UX 5 UI
Chipset	Qualcomm MSM8996 Snapdragon 820 (14 nm)
CPU	Quad-core (2x2.15 GHz Kryo & 2x1.6 GHz Kryo)
GPU	Adreno 530

Memory
Card slot	microSD, up to 512 GB (uses SIM 2 slot) - dual SIM model only
Internal	32 GB, 4 GB RAM

Main Camera
Dual	16 MP, f/1.8, 26mm (wide), 1/2.6", laser AF, 3-axis OIS 8 MP, f/2.4, 9mm, 1/3.6", no AF
Features	LED flash, panorama, HDR
Video	2160p@30fps, 1080p@30/60fps, HDR, stereo sound rec.

Selfie Camera
Single	8 MP, f/2.0, 1/4", 1.12µm
Video	1080p@30fps

Sound
Loudspeaker	Yes
3.5mm jack	Yes
	24-bit/192kHz audio Active noise cancellation with dedicated mic

Comms
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.2, A2DP, LE, aptX HD
GPS	Yes, with A-GPS, GLONASS, BDS
NFC	Yes
Infrared port	Yes
Radio	FM radio
USB	3.0, Type-C 1.0 reversible connector, USB On-The-Go

Features
Sensors	Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, color spectrum

Battery
	Removable Li-Ion 2800 mAh battery
Charging	Fast battery charging 18W (Quick Charge 3.0)
Stand-by	Up to 400 h (3G)
Talk time	Up to 20 h (3G)

Misc
Colors	Silver, Titan, Gold, Pink
Models	H860, H850, F700L, VS987, H830, H831, H820, H840, LGLS992, LGUS992
SAR EU	0.52 W/kg (head)     1.24 W/kg (body)
Price	About 300 EUR

Tests
Performance	Basemark OS II: 2425 / Basemark OS II 2.0: 2314 Basemark X: 27577
Display	Contrast ratio: 1855:1 (nominal), 2.905 (sunlight)
Camera	Photo / Video
Loudspeaker	Voice 68dB / Noise 70dB / Ring 73dB
Audio quality	Noise -92.6dB / Crosstalk -93.3dB
Battery life	Endurance rating 60h
