Samsung Galaxy S20+ 5G
Specifications
$ 180.11
Also available with 4G/LTE only
Versions: SM-G986B, SM-G986F (International); SM-G986U (USA); SM-G986U1 (USA Unlocked); SM-G986W (Canada); SM-G9860 (China, Hong Kong); SM-G986N (Korea)
| Network | |
|---|---|
| Technology | GSM / CDMA / HSPA / EVDO / LTE / 5G |
| 2G bands | GSM 850 / 900 / 1800 / 1900 |
| CDMA 800 / 1900 & TD-SCDMA | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 |
| CDMA2000 1xEV-DO | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66 - SM-G986B |
| 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 46, 48, 66, 71 - SM-G986U | |
| 5G bands | 1, 3, 5, 7, 8, 28, 40, 77, 78 SA/NSA/Sub6 - SM-G986B |
| 2, 5, 41, 66, 71, 260, 261 SA/NSA/Sub6/mmWave - SM-G986U | |
| Speed | HSPA 42.2/5.76 Mbps, LTE (7CA) Cat20 2000/200 Mbps, 5G (5+ Gbps DL) |
| Launch | |
|---|---|
| Announced | 2020, February 11 |
| Status | Available. Released 2020, March 06 |
| Body | |
|---|---|
| Dimensions | 161.9 x 73.7 x 7.8 mm (6.37 x 2.90 x 0.31 in) |
| Weight | 188 g (6.63 oz) |
| Build | Glass front (Gorilla Glass 6), glass back (Gorilla Glass 6), aluminum frame |
| SIM | Nano-SIM + eSIM Nano-SIM + Nano-SIM |
| IP68 dust tight and water resistant (immersible up to 1.5m for 30 min) | |
| Display | |
|---|---|
| Type | Dynamic AMOLED 2X, 120Hz, HDR10+, 1200 nits (peak) |
| Size | 6.7 inches, 108.0 cm2 (~90.5% screen-to-body ratio) |
| Resolution | 1440 x 3200 pixels, 20:9 ratio (~525 ppi density) |
| Protection | Corning Gorilla Glass 6 |
| Always-on display 120Hz@FHD/60Hz@QHD refresh rate | |
| Platform | |
|---|---|
| OS | Android 10, upgradable to Android 13, One UI 5.1 |
| Chipset | Exynos 990 (7 nm+) - Global Qualcomm SM8250 Snapdragon 865 5G (7 nm+) - USA |
| CPU | Octa-core (2x2.73 GHz Mongoose M5 & 2x2.50 GHz Cortex-A76 & 4x2.0 GHz Cortex-A55) - Global Octa-core (1x2.84 GHz Cortex-A77 & 3x2.42 GHz Cortex-A77 & 4x1.80 GHz Cortex-A55) - USA |
| GPU | Mali-G77 MP11 - Global Adreno 650 - USA |
| Memory | |
|---|---|
| Card slot | microSDXC (uses shared SIM slot) |
| Internal | 128GB 8GB RAM, 128GB 12GB RAM, 256GB 12GB RAM, 512GB 12GB RAM |
| UFS 3.0 | |
| Main Camera | |
|---|---|
| Triple | 12 MP, f/1.8, 26mm (wide), 1/1.76", 1.8µm, dual pixel PDAF, OIS 64 MP, f/2.0, 29mm (telephoto), 1/1.72", 0.8µm, PDAF, OIS, 1.1x optical zoom, 3x hybrid zoom 12 MP, f/2.2, 13mm, 120˚ (ultrawide), 1/2.55" 1.4µm, Super Steady video 0.3 MP, TOF 3D, f/1.0, (depth) |
| Features | LED flash, auto-HDR, panorama |
| Video | 8K@24fps, 4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS |
| Selfie Camera | |
|---|---|
| Single | 10 MP, f/2.2, 26mm (wide), 1/3.24", 1.22µm, dual pixel PDAF |
| Features | HDR |
| Video | 4K@30/60fps, 1080p@30fps |
ADVERTISEMENT
| Sound | |
|---|---|
| Loudspeaker | Yes, with stereo speakers |
| 3.5mm jack | No |
| 32-bit/384kHz audio Tuned by AKG | |
| Comms | |
|---|---|
| WLAN | Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct |
| Bluetooth | 5.0, A2DP, LE |
| Positioning | GPS, GLONASS, BDS, GALILEO |
| NFC | Yes |
| Radio | FM radio (Snapdragon model only; market/operator dependent) |
| USB | USB Type-C 3.2, OTG |
| Features | |
|---|---|
| Sensors | Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer |
| Samsung DeX, Samsung Wireless DeX (desktop experience support) ANT+ | |
| Battery | |
|---|---|
| Type | Li-Ion 4500 mAh |
| Charging | 25W wired, PD3.0 15W wireless (Qi) 4.5W reverse wireless |
| Misc | |
|---|---|
| Colors | Cosmic Black, Cosmic Grey, Cloud Blue, Cloud White, Aura Red, Aura Blue |
| Models | SM-G986, SM-G986F, SM-G986F/DS, SM-G986U, SM-G986U1, SM-G9860, SM-G986B/DS, SM-G986N, SM-G986B, SM-G986W, SCG02 |
| SAR | 1.08 W/kg (head) 1.02 W/kg (body) |
| SAR EU | 1.09 W/kg (head) 1.57 W/kg (body) |
| Price | $ 180.11 / C$ 899.97 / £ 170.00 / € 318.00 |
