Sony Xperia Z5 Compact
Specifications
| Network | |
|---|---|
| Technology | GSM / HSPA / LTE |
| 2G bands | GSM 850 / 900 / 1800 / 1900 |
| 3G bands | HSDPA 850 / 900 / 1900 / 2100 - E5803, E5823 |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 28, 38, 40 - E5803, E5823 |
| Speed | HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps (E5803), LTE Cat6 300/50 Mbps (E5823) |
| Launch | |
|---|---|
| Announced | 2015, September. Released 2015, October |
| Status | Discontinued |
| Body | |
|---|---|
| Dimensions | 127 x 65 x 8.9 mm (5.0 x 2.56 x 0.35 in) |
| Weight | 138 g (4.87 oz) |
| Build | Glass front, glass back, plastic frame |
| SIM | Nano-SIM |
| IP68 dust/water resistant (up to 1.5m for 30 min) | |
| Display | |
|---|---|
| Type | IPS LCD |
| Size | 4.6 inches, 56.9 cm2 (~68.9% screen-to-body ratio) |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~323 ppi density) |
| Protection | Scratch-resistant glass, oleophobic coating |
| Triluminos display X-Reality Engine | |
| Platform | |
|---|---|
| OS | Android 5.1.1 (Lollipop), upgradable to 7.1.1 (Nougat) |
| Chipset | Qualcomm MSM8994 Snapdragon 810 (20 nm) |
| CPU | Octa-core (4x1.5 GHz Cortex-A53 & 4x2.0 GHz Cortex-A57) |
| GPU | Adreno 430 |
| Memory | |
|---|---|
| Card slot | microSDXC (dedicated slot) |
| Internal | 32GB 2GB RAM |
| eMMC 5.0 | |
| Main Camera | |
|---|---|
| Single | 23 MP, f/2.0, 24mm (wide), 1/2.3", PDAF |
| Features | LED flash, HDR, panorama |
| Video | 4K@30fps, 1080p@60fps, 720p@120fps, HDR |
| Selfie Camera | |
|---|---|
| Single | 5.1 MP, f/2.4 |
| Features | HDR |
| Video | 1080p@30fps |
ADVERTISEMENT
| Sound | |
|---|---|
| Loudspeaker | Yes, with stereo speakers |
| 3.5mm jack | Yes |
| 24-bit/192kHz audio | |
| Comms | |
|---|---|
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot |
| Bluetooth | 4.1, A2DP, aptX |
| Positioning | GPS, GLONASS/ BDS (market dependant) |
| NFC | Yes |
| Radio | FM radio, RDS |
| USB | microUSB 2.0 (MHL 3 TV-out), OTG |
| Features | |
|---|---|
| Sensors | Fingerprint (side-mounted; EU model only), accelerometer, gyro, proximity, compass, barometer |
| ANT+ | |
| Battery | |
|---|---|
| Type | Li-Ion 2700 mAh, non-removable |
| Charging | 18W wired, QC2 |
| Stand-by | Up to 520 h (2G) / Up to 520 h (3G) |
| Talk time | Up to 11 h 30 min (2G) / Up to 14 h 50 min (3G) |
| Music play | Up to 77 h |
| Misc | |
|---|---|
| Colors | White, Graphite Black, Yellow, Coral |
| Models | SO-02H, E5823, E5803 |
| SAR | 0.97 W/kg (head) 0.72 W/kg (body) |
| SAR EU | 1.07 W/kg (head) 0.71 W/kg (body) |
| Price | About 200 EUR |
| Tests | |
|---|---|
| Performance | Basemark OS II 2.0: 1440Basemark X: 23703 |
| Display | Contrast ratio: 1053 (nominal), 2.78(sunlight) |
| Camera | Photo / Video |
| Loudspeaker | Voice 66dB / Noise 65dB / Ring 70dB |
| Audio quality | Noise -95.9dB / Crosstalk -94.4dB |
| Battery (old) | Endurance rating 86h |
